High-Performance Industrial Networking

The Teltonika TSW200 combines high-speed Gigabit Ethernet, PoE+ power delivery, and fibre connectivity in a rugged industrial switch. Its eight Gigabit Ethernet ports provide network connectivity and PoE+ power to compatible devices, while two SFP ports allow fibre-optic connections for longer-distance network links.

The switch operates as an unmanaged plug-and-play device, making it simple to deploy where advanced switch configuration is not required.

Key Features

8 Gigabit Ethernet Ports: Supports 10/100/1000 Mbps connectivity.
8 PoE+ Ports: All eight Ethernet ports support IEEE 802.3af and 802.3at PoE standards.
Up to 30 W per Port: Provides up to 30 W PoE output per port at the PSE.
240 W Total PoE Budget: Supports a total PoE power budget of up to 240 W.
2 SFP Ports: Enables fibre-optic connectivity for longer-distance network links.
20 Gbps Switching Bandwidth: Non-blocking bandwidth for efficient network traffic handling.
2K MAC Address Table: Supports up to 2,000 MAC address entries.
Jumbo Frames: Supports frames up to 9,216 bytes.
Auto MDI/MDIX: Automatically detects Ethernet cable connection requirements.
Wide DC Input: Supports the specified industrial DC power range.
Industrial Aluminium Housing: Rugged housing designed for demanding environments.
Flexible Mounting: Supports DIN rail, wall mounting with an additional kit, and flat-surface placement.
Industrial Temperature Range: Designed for operation from -40C to +75C.

Fibre & PoE+ Connectivity

The combination of 8 PoE+ Gigabit ports and 2 SFP ports makes the TSW200 suitable for network installations where both powered Ethernet devices and long-distance fibre links are required.

It can provide power and data connectivity to compatible IP cameras, wireless access points, routers, industrial equipment, and other PoE-enabled devices while using SFP connections to extend the network over fibre.
