Teltonika RUTX11: Industrial 4G LTE Cat 6 Gigabit Router

Teltonika RUTX11 is an industrial 4G LTE Cat 6 router designed for professional applications that require fast and reliable network connectivity. It combines LTE Cat 6, dual SIM, Wi-Fi 5, Bluetooth Low Energy, and four Gigabit Ethernet ports in a compact industrial networking solution.

The router is suitable for deployments where high data throughput and flexible connectivity are important. With wired and wireless interfaces available in one device, it can support different business, industrial, and remote networking requirements.

Table of Contents

• Key Features
• 4G LTE Cat 6 and Dual-SIM Connectivity
• Wi-Fi 5 and Gigabit Ethernet
• Network Management and Security
• Applications
• Technical Specifications
• Buy Teltonika RUTX11 in India
• Frequently Asked Questions

Teltonika RUTX11 Key Features

Teltonika RUTX11 brings together cellular, Ethernet, Wi-Fi, and Bluetooth connectivity for professional networking environments. Its LTE Cat 6 modem supports Carrier Aggregation and cellular speeds of up to 300 Mbps, while four Gigabit Ethernet ports provide high-speed wired connections.

The router also provides two Mini SIM slots with automatic failover and backup WAN capabilities. As a result, network administrators have more flexibility when configuring primary and backup connectivity for remote or demanding installations.

• 4G LTE Cat 6 connectivity
• Cellular speeds up to 300 Mbps with Carrier Aggregation
• Dual SIM with automatic failover
• Backup WAN and network switching options
• Dual-band Wi-Fi 5 with 802.11ac Wave 2
• Bluetooth Low Energy connectivity
• 4 × Gigabit Ethernet ports
• Up to 128 port-based or tag-based VLANs
• USB host interface
• GNSS support
• Industrial aluminium housing

4G LTE Cat 6 and Dual-SIM Connectivity

The LTE Cat 6 modem provides fast cellular connectivity with Carrier Aggregation and download speeds of up to 300 Mbps. It also supports 3G connectivity, providing additional network compatibility for suitable deployments.

Two Mini SIM slots allow the router to use dual-SIM configurations. Automatic SIM switching can be configured around conditions such as weak signal, data limits, roaming, network availability, and other supported parameters.

Because remote locations can depend on cellular connectivity, automatic failover can help maintain network access when the primary connection becomes unavailable. The device also supports backup WAN functionality and other network switching scenarios.

Wi-Fi 5 and Gigabit Ethernet

The integrated wireless interface supports IEEE 802.11b/g/n/ac Wave 2, providing Wi-Fi 5 connectivity across dual bands. It supports data transmission rates of up to 867 Mbps, along with MU-MIMO, Access Point mode, and Station mode.

For example, wireless devices can connect through Wi-Fi while wired equipment uses the Gigabit Ethernet ports. Bluetooth Low Energy is also available for supported short-range wireless communication requirements.

The four RJ45 Ethernet ports support 10/100/1000 Mbps connections. One port can operate as WAN, while the remaining interfaces provide LAN connectivity, and VLAN functionality allows supported network segmentation configurations.

Network Management and Security

Teltonika RUTX11 uses RutOS, Teltonika Networks’ operating system for its networking and management functions. Supported capabilities include IPv4 and IPv6, static and dynamic routing, DHCP, DNS, firewall configuration, VLANs, QoS, load balancing, and connection monitoring.

The router supports multiple VPN technologies, including OpenVPN, IPsec, GRE, PPTP, L2TP, DMVPN, WireGuard, ZeroTier, and Tailscale. However, the appropriate configuration depends on the requirements and architecture of the individual network.

Remote management is available through Teltonika Networks Remote Management System. Consequently, compatible deployments can be monitored and administered through centralized management tools.

Applications

Teltonika RUTX11 can be deployed in professional environments that require cellular connectivity together with high-speed Ethernet and wireless networking. Its combination of LTE, dual SIM, Wi-Fi, Bluetooth, and Gigabit Ethernet supports a variety of connectivity scenarios.

• Industrial networking
• Remote site connectivity
• Business and branch-office networking
• Industrial IoT deployments
• Backup Internet connectivity
• Remote equipment monitoring
• Transportation networking
• Professional Wi-Fi deployments
• High-speed Ethernet networking

Technical Specifications

• Product Type: Industrial Cellular Router
• Mobile Connectivity: 4G LTE Cat 6, 3G
• LTE Speed: Up to 300 Mbps with Carrier Aggregation
• SIM: 2 × Mini SIM (2FF)
• Wi-Fi: IEEE 802.11b/g/n/ac Wave 2, Wi-Fi 5
• Wi-Fi Speed: Up to 867 Mbps
• Wi-Fi Features: Dual Band, MU-MIMO, Access Point, Station
• Bluetooth: Bluetooth Low Energy
• Ethernet: 4 × RJ45, 10/100/1000 Mbps
• WAN: 1 × WAN
• LAN: 3 × LAN
• VLAN: Up to 128 port-based or tag-based VLANs
• USB: 1 × USB A port for external devices
• GNSS: Supported
• Digital I/O: 1 × Digital Input and 1 × Digital Output
• Power Input: 9–50 VDC
• Power Consumption: Up to 16 W
• Operating Temperature: -40°C to +75°C
• Ingress Protection: IP30
• Housing: Aluminium
• Dimensions: 115 × 44.2 × 95.1 mm
• Weight: Approximately 456 g
• Mounting: DIN rail, wall mount and flat-surface placement with additional kit

Buy Teltonika RUTX11 in India

Teltonika RUTX11 is designed for businesses and industrial deployments that require 4G LTE Cat 6 connectivity, dual SIM, Wi-Fi 5, and Gigabit Ethernet. Its flexible connectivity and network management capabilities make it suitable for primary connectivity as well as backup networking applications.

If you are comparing professional networking products for your deployment, explore Ethernet routers from AirPath for related networking solutions.

For complete technical information, documentation, and current manufacturer specifications, visit the official Teltonika RUTX11 product page.

Frequently Asked Questions

What is Teltonika RUTX11?

Teltonika RUTX11 is an industrial 4G LTE Cat 6 router that combines cellular connectivity with dual SIM, Wi-Fi 5, Bluetooth Low Energy, and four Gigabit Ethernet ports.

Does Teltonika RUTX11 support dual SIM?

Yes. The router has two Mini SIM slots and supports automatic SIM switching, failover, backup WAN, and other supported network switching scenarios.

Does Teltonika RUTX11 support Wi-Fi 5?

Yes. The router supports dual-band IEEE 802.11b/g/n/ac Wave 2 Wi-Fi 5 with MU-MIMO, Access Point mode, and Station mode.

How many Ethernet ports does Teltonika RUTX11 have?

Teltonika RUTX11 has four RJ45 Gigabit Ethernet ports supporting 10/100/1000 Mbps connections, including one WAN interface and three LAN interfaces.

Where can Teltonika RUTX11 be used?

It can be used for industrial networking, remote sites, business connectivity, industrial IoT, transportation networking, and applications requiring high-speed cellular and Ethernet connectivity.
